FOM Technologies
Slot-Die Coater
Scalable precision coating from lab to pilot production.
Genuine Product
1 Year Warranty
Expert Support
Hover to zoom
Overview
The FOM Technologies slot-die coater enables scalable, roll-to-roll compatible thin-film coating with exceptional thickness control. Suitable for organic photovoltaics, printed electronics, and battery electrode coating, the system features adjustable coating width, integrated drying, and automated meniscus guide for ultra-uniform wet films from 500nm to 500μm.
Key Capabilities
Roll-to-roll compatible slot-die head
Wet film thickness 500nm – 500μm
Adjustable coating width up to 300mm
Integrated IR and hot-air drying zones
Automated meniscus guide for uniform films
Recipe-based operation with data logging
Applications
Organic PhotovoltaicsPrinted ElectronicsBattery Electrode CoatingFuel Cell MembranesFunctional CoatingsBiomedical Films
Technical Specifications
Coating Width
Up to 300 mm
Film Thickness
500 nm – 500 μm
Web Speed
0.1 – 50 m/min
Substrate Width
Up to 350 mm
Drying
IR + Hot Air, up to 200°C
Power
380V AC, 3-Phase
Warranty
1 Year Comprehensive
1 Year Warranty
Fast Support
ISO Certified
